DL ECT1250 U7-265 32 1 W11P

DL ECT1250 U7-265 32 1 W11P

PAIA version

GaBi version 1, 2024

Total carbon emissions, standard deviation (kg of CO2e)

Total carbon footprint (kg of CO2e)

214

Carbon emissions, manufacturing (kg of CO2e)

112.992

Carbon emissions, logistics (kg of CO2e)

10.272

Carbon emissions, energy usage (kg of CO2e)

84.316

Carbon emissions, end-of-life (kg of CO2e)

6.42

Total carbon emissions, w/o use phase (kg of CO2e)

129.684

Processor model

265

Processor family

Intel Core Ultra 7

Operating system installed

Windows 11 Pro

Cable lock slot

Yes

Cable lock slot type

Kensington

Product colour

Black

Chassis type

Tower

Placement supported

Vertical

Product type

PC

Display included

No

PCI Express x16 slots

1

PCI Express x1 slots

2

Power Supply

180 W

Memory slots

2x DIMM

Weight

6.86 kg

Audio Chip

Realtek ALC3204

On-board graphics card family

Intel Graphics

On-board graphics card

Yes

Discrete graphics card

No

Discrete graphics card model

Not available

On-board graphics card model

Intel Graphics

On-board GPU manufacturer

Intel

Maximum internal memory

64 GB

Internal memory type

DDR5-SDRAM

Memory channels

Single-channel

Memory data transfer rate

5600 MT/s

Total storage capacity

1 TB

Memory layout (slots x size)

1 x 32 GB

Cabling technology

10/100/1000Base-T(X)

LAN controller

Realtek RTL8111KD

WLAN controller model

MediaTek MT7920

WLAN controller manufacturer

MediaTek

Wi-FI

Yes

Wi-Fi standards

802.11a, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n)

Bluetooth

Yes

Top Wi-Fi standard

Wi-Fi 6 (802.11ax)

Antenna type

2x2

Ethernet LAN

Yes

Ethernet LAN data rates

10,100,1000 Mbit/s

Neural processor unit (NPU)

Intel AI Boost

Sparsity support

Yes

Windows Studio effects support

Yes

AI software frameworks supported by NPU

DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

NPU performance up to

13 TOPs

GPU performance up to

8 TOPs

Total processor performance up to

33 TOPs

Storage temperature (T-T)

-40 - 65 °C

Operating temperature (T-T)

10 - 35 °C

Operating relative humidity (H-H)

10 - 90%

Storage relative humidity (H-H)

0 - 95%

Operating altitude

-15.2 - 3048 m

Non-operating altitude

-15.2 - 10668 m

Operating shock

110 G

Non-operating shock

160 G

Operating vibration

0.66 G

Non-operating vibration

1.3 G

Motherboard chipset

Intel Q870

Audio system

High Definition Audio

Trusted Platform Module (TPM)

Yes

Trusted Platform Module (TPM) version

2.0

Combo headphone/mic port

Yes

HDMI ports quantity

1

Ethernet LAN (RJ-45) ports

1

HDMI version

2.1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

3

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

0

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

1

Thunderbolt 3 ports quantity

0

DisplayPorts quantity

1

USB 2.0 ports quantity

4

DisplayPort version

1.4a

Number of SATA III connectors

1

Power supply input frequency

47/63 Hz

Power supply input voltage

90 - 264 V

80 PLUS certification

80 PLUS Bronze

Efficient-core Max Turbo Frequency

4.6 GHz

Performance-core base frequency

2.4 GHz

Processor generation

Intel Core Ultra (Series 2)

Maximum turbo power

182 W

Performance-core Max Turbo Frequency

5.2 GHz

Processor base power

65 W

Efficient-core base frequency

1.8 GHz

Processor threads

20

Number of processors installed

1

Processor cache

30 MB

Performance cores

8

Processor cores

20

Efficient cores

12

Processor boost frequency

5.3 GHz

Processor manufacturer

Intel

Processor cache type

Smart Cache

Operating system architecture

64-bit

Trial software

McAfee LiveSafe 1-year (5-device),Activate Your Microsoft 365 For A 30 Day Trial

Total SSDs capacity

1 TB

Number of storage drives installed

1

Storage media

SSD

Optical drive type

No

Number of SSDs installed

1

SSD interface

PCI Express 4.0

SSD form factor

M.2

NVMe

Yes

Number of storage drives supported

2

M.2 SSD size

2230 (22 x 30 mm)

SSD capacity

1 TB

Sustainability certificates

ENERGY STAR, EPEAT Climate +, EPEAT Silver

Depth

293 mm

Width

154 mm

Height

324.3 mm
