DL FCM2250 U7-265U 32 1 A1000 W11P

DL FCM2250 U7-265U 32 1 A1000 W11P

VGA

No

PAIA version

GaBi version 1, 2024

Total carbon footprint (kg of CO2e)

183

Carbon emissions, manufacturing (kg of CO2e)

63.318

Carbon emissions, logistics (kg of CO2e)

3.66

Carbon emissions, energy usage (kg of CO2e)

114.741

Carbon emissions, end-of-life (kg of CO2e)

1.28

Processor model

265U

Processor family

Intel Core Ultra 7

Operating system installed

Windows 11 Pro

Bluetooth

Yes

Product colour

Black

Product type

PC

Chassis type

Micro PC

Cable lock slot type

Kensington

Cable lock slot

Yes

Intel® vPro™ Platform Eligibility

Yes

Display included

No

Power Supply

280 W

Weight

2.54 kg

Memory slots

2x SO-DIMM

Audio Chip

Realtek ALC3204

Number of discrete graphics cards

1

Discrete graphics card

Yes

Discrete GPU manufacturer

NVIDIA

Discrete graphics memory type

GDDR6

On-board graphics card

Yes

On-board graphics card model

Intel Graphics

On-board GPU manufacturer

Intel

Graphics card Mini DisplayPort ports quantity

4

On-board graphics card family

Intel Graphics

Discrete graphics card model

NVIDIA RTX A1000

Discrete graphics card memory

8 GB

Memory layout (slots x size)

1 x 32 GB

Non-ECC

Yes

Total storage capacity

1 TB

Maximum internal memory

64 GB

Internal memory type

DDR5-SDRAM

Memory channels

Single-channel

Memory data transfer rate

5600 MT/s

Wi-FI

Yes

Top Wi-Fi standard

Wi-Fi 7 (802.11be)

WLAN controller model

Intel Wi-Fi 7 BE200

Antenna type

2x2

WLAN controller manufacturer

Intel

Ethernet LAN

Yes

Ethernet LAN data rates

10,100,1000 Mbit/s

LAN controller

Intel® I219-LM

Cabling technology

10/100/1000Base-T(X)

AI software frameworks supported by NPU

DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

Neural processor unit (NPU)

Intel AI Boost

Sparsity support

Yes

Windows Studio effects support

Yes

Storage relative humidity (H-H)

0 - 95%

Operating altitude

-15.2 - 3048 m

Non-operating altitude

-15.2 - 10668 m

Operating shock

110 G

Non-operating shock

160 G

Operating vibration

0.66 G

Non-operating vibration

1.3 G

Operating relative humidity (H-H)

10 - 90%

Operating temperature (T-T)

0 - 35 °C

Storage temperature (T-T)

-40 - 65 °C

Motherboard chipset

Intel W880

Audio system

High Definition Audio

Trusted Platform Module (TPM)

Yes

Trusted Platform Module (TPM) version

2.0

Market positioning

Business

Combo headphone/mic port

Yes

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

DC-in jack

Yes

Ethernet LAN (RJ-45) ports

1

Number of rear USB ports

5

Number of front audio ports

1

Number of front USB ports

3

DisplayPorts quantity

3

DisplayPort version

1.4a

Thunderbolt 3 ports quantity

0

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

4

USB 2.0 ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

0

USB 3.2 Gen 2x2 Type-C ports quantity

1

Power supply input voltage

100 - 240 V

Power supply input frequency

50 / 60 Hz

Low Power Efficient-core Max Turbo Frequency

2.4 GHz

Efficient-core base frequency

1.7 GHz

Performance-core base frequency

2.1 GHz

Processor boost frequency

5.3 GHz

Number of processors installed

1

Processor generation

Intel Core Ultra (Series 2)

Efficient-core Max Turbo Frequency

4.2 GHz

Processor manufacturer

Intel

Processor cores

12

Processor threads

14

Performance cores

2

Efficient cores

8

Low Power Efficient-cores

2

Low Power Efficient-core Base Frequency

700 MHz

Processor cache

12 MB

Processor base power

15 W

Maximum turbo power

57 W

Performance-core Max Turbo Frequency

5.3 GHz

Operating system architecture

64-bit

Total SSDs capacity

1 TB

SSD memory type

TLC

Storage media

SSD

Optical drive type

No

Number of SSDs installed

1

SSD interface

PCI Express 4.0

SSD form factor

M.2

NVMe

Yes

Number of storage drives supported

2

M.2 SSD size

2280 (22 x 80 mm)

SSD capacity

1 TB

Number of storage drives installed

1

Sustainability certificates

ENERGY STAR, EPEAT Climate +, EPEAT Gold

Depth

178 mm

Width

79.3 mm

Height

206 mm

WS-CPU

Intel-Core-i

WS-Format

SFF
