DL MA16250 FHD+ U9-285H 64 1 PRO2000 WP

DL MA16250 FHD+ U9-285H 64 1 PRO2000 WP

Number of built-in speakers

4

Audio Chip

Cirrus Logic CS42L43

Built-in microphone

Yes

Audio system

Dolby Atmos

Number of battery cells

6

Battery weight

351 g

Battery capacity

96 Wh

Battery technology

Lithium-Ion (Li-Ion)

Battery recharge time

3 h

Battery voltage

11.7 V

Fast charging

Yes

Brand specific technologies

Battery-saving Mini-LED, Express Charge Boost capable, ExpressSign-In, Intelligent Privacy, TNR

Front camera

Yes

Video capturing speed

30 fps

Infrared (IR) camera

Yes

Front camera resolution

2560 x 1440 pixels

Front camera resolution (numeric)

8 MP

Intel® vPro™ Platform Eligibility

Yes

Form factor

Clamshell

Product type

Mobile workstation

HD type

Full HD

Display brightness

500 cd/m²

Anti-glare screen

Yes

Native aspect ratio

16:10

Pixel density

142 ppi

Colour gamut

100%

RGB colour space

DCI-P3

Display response rise/fall

35 ms

Panel type

WVA

Maximum refresh rate

120 Hz

Contrast ratio (typical)

1500:1

Display resolution

1920 x 1200 pixels

Display diagonal

40.6 cm (16)

Touchscreen

No

Fingerprint reader

Yes

Weight

2.19 kg

On-board graphics card

Yes

On-board GPU manufacturer

Intel

Discrete graphics card

Yes

Discrete GPU manufacturer

NVIDIA

On-board graphics card family

Intel Arc Graphics

Discrete graphics card model

NVIDIA RTX PRO 2000 Blackwell

Discrete graphics memory type

GDDR7

On-board graphics card model

Intel Arc 140T

Discrete graphics card memory

8 GB

Spill-resistant keyboard

Yes

Copilot key

Yes

Keyboard language

English

Pointing device

Touchpad

Numeric keypad

No

Keyboard backlit

Yes

Maximum internal memory

64 GB

Memory form factor

On-board

Internal memory type

LPDDR5x-SDRAM

Memory data transfer rate

8400 MT/s

MIMO

Yes

MIMO type

Multi User MIMO

Top Wi-Fi standard

Wi-Fi 7 (802.11be)

WLAN controller model

Intel Wi-Fi 7 BE201

Wi-Fi band

Tri-band (2.4 GHz / 5 GHz / 6 GHz)

Bluetooth

Yes

Ethernet LAN

No

Mobile network connection

No

Antenna type

2x2

WLAN controller manufacturer

Intel

Neural processor unit (NPU)

Intel AI Boost

Sparsity support

Yes

Windows Studio effects support

Yes

Total processor performance up to

99 TOPs

GPU performance up to

77 TOPs

AI software frameworks supported by NPU

DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

NPU performance up to

13 TOPs

Operating temperature (T-T)

0 - 35 °C

Storage temperature (T-T)

-40 - 65 °C

Operating relative humidity (H-H)

10 - 90%

Storage relative humidity (H-H)

0 - 95%

Operating altitude

-15.2 - 3048 m

Non-operating altitude

-15.2 - 10668 m

Operating shock

110 G

Non-operating shock

160 G

Operating vibration

0.66 G

Non-operating vibration

1.3 G

AC adapter included

Yes

Processor model

285H

Processor family

Intel Core Ultra 9

Accelerometer

Yes

Hall sensor

Yes

Motherboard chipset

Intel SoC

Operating system installed

Windows 11 Pro

Performance cores

6

Efficient cores

8

Processor manufacturer

Intel

Ambient light sensor

Yes

Intel® Thunderbolt 4

Yes

Combo headphone/mic port

Yes

Card reader integrated

Yes

HDMI ports quantity

1

HDMI version

2.1

USB Type-C DisplayPort Alternate Mode

Yes

USB 2.0 ports quantity

0

Thunderbolt 4 ports quantity

1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

0

USB Power Delivery (USB PD)

Yes

Intel® Thunderbolt 5

Yes

Thunderbolt 5 ports quantity

2

USB Type-C charging port

Yes

USB charging voltage

5,9,15,20 V

AC adapter power

165 W

AC adapter frequency

50/60 Hz

AC adapter input voltage

100 - 240 V

Low Power Efficient-cores

2

Low Power Efficient-core Max Turbo Frequency

2.5 GHz

Processor cache

24 MB

Maximum turbo power

115 W

Processor cores

16

Processor base power

45 W

Processor threads

16

Processor boost frequency

5.4 GHz

Efficient-core base frequency

2.7 GHz

Performance-core Max Turbo Frequency

5.4 GHz

Processor generation

Intel Core Ultra (Series 2)

Low Power Efficient-core Base Frequency

1000 MHz

Efficient-core Max Turbo Frequency

4.5 GHz

Performance-core base frequency

2.9 GHz

Cable lock slot

Yes

Cable lock slot type

Wedge

Trusted Platform Module (TPM)

Yes

Trusted Platform Module (TPM) version

2.0

Operating system architecture

64-bit

Trial software

McAfee Business Protection 1-year (Disti Only),Activate Your Microsoft 365 For A 30 Day Trial

Compatible memory cards

SD, SDHC, SDXC

Total SSDs capacity

1 TB

Total storage capacity

1 TB

SSD form factor

M.2

NVMe

Yes

SSD capacity

1 TB

Storage media

SSD

Optical drive type

No

Number of SSDs installed

1

SSD interface

PCI Express 4.0

Height (rear)

2.08 cm

Height (front)

2.08 cm

Width

353.8 mm

Depth

240.3 mm
