DL MB16250 FHD U9-285HX 64 1 PRO3000 WP

DL MB16250 FHD U9-285HX 64 1 PRO3000 WP

Number of built-in speakers

2

Speaker power

2 W

Number of microphones

2

Audio Chip

Cirrus Logic CS42L43

Built-in microphone

Yes

Battery capacity

96 Wh

Battery technology

Lithium-Ion (Li-Ion)

Battery recharge time

3 h

Battery voltage

11.7 V

Fast charging

Yes

Number of battery cells

6

Brand specific technologies

TNR, Express Charge Boost capable

Front camera resolution

1920 x 1080 pixels

Front camera HD type

Full HD

Video capturing speed

30 fps

Infrared (IR) camera

Yes

Privacy camera

Yes

Privacy type

Privacy shutter

Front camera

Yes

Front camera resolution (numeric)

8.29 MP

Windows Hello

Yes

Intel® vPro™ Platform Eligibility

Yes

Form factor

Clamshell

Product type

Mobile workstation

HD type

Full HD

Display brightness

500 cd/m²

Anti-glare screen

Yes

Pixel density

141 ppi

RGB colour space

DCI-P3

Native aspect ratio

16:10

Colour gamut

100%

Panel type

WVA

Maximum refresh rate

120 Hz

Display response rise/fall

35 ms

Contrast ratio (typical)

1500:1

Display technology marketing name

ComfortView Plus

Display resolution

1920 x 1200 pixels

Display diagonal

40.6 cm (16)

Touchscreen

No

Weight

2.55 kg

Fingerprint reader

Yes

On-board graphics card

Yes

On-board graphics card model

Intel Graphics

On-board GPU manufacturer

Intel

Discrete graphics card

Yes

Discrete GPU manufacturer

NVIDIA

Discrete graphics memory type

GDDR7

Discrete graphics card model

NVIDIA RTX PRO 2000 Blackwell

Discrete graphics card memory

8 GB

On-board graphics card family

Intel Graphics

Keyboard language

English

Copilot key

Yes

Numeric keypad

Yes

Pointing device

Touchpad

Keyboard backlit

Yes

Memory channels

Dual-channel

Memory clock speed

6400 MHz

Maximum internal memory

64 GB

Internal memory type

DDR5-SDRAM

Non-ECC

Yes

Memory layout (slots x size)

2 x 16 GB

Ethernet LAN data rates

10,100,1000,2500 Mbit/s

Wi-Fi band

Tri-band (2.4 GHz / 5 GHz / 6 GHz)

Wi-Fi data rate (max)

5760 Mbit/s

Near Field Communication (NFC)

Yes

Bluetooth

Yes

Top Wi-Fi standard

Wi-Fi 7 (802.11be)

WLAN controller model

Intel Wi-Fi 7 BE200

Mobile network connection

No

WLAN controller manufacturer

Intel

Ethernet LAN

Yes

Neural processor unit (NPU)

Intel AI Boost

Sparsity support

Yes

Windows Studio effects support

Yes

Total processor performance up to

36 TOPs

AI software frameworks supported by NPU

DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

NPU performance up to

13 TOPs

GPU performance up to

8 TOPs

Operating relative humidity (H-H)

10 - 90%

Operating temperature (T-T)

0 - 35 °C

Storage temperature (T-T)

-40 - 65 °C

Storage relative humidity (H-H)

0 - 95%

Operating altitude

-15.2 - 3048 m

Non-operating altitude

-15.2 - 10668 m

Operating shock

110 G

Non-operating shock

160 G

Operating vibration

0.66 G

Non-operating vibration

1.3 G

AC adapter included

Yes

Processor model

285HX

Processor family

Intel Core Ultra 9

Efficient cores

16

Performance cores

8

Operating system installed

Windows 11 Pro

Accelerometer

Yes

Hall sensor

Yes

Processor manufacturer

Intel

Ambient light sensor

Yes

Intel® Thunderbolt 4

Yes

Combo headphone/mic port

Yes

Card reader integrated

Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

HDMI ports quantity

1

HDMI version

2.1

USB Type-C DisplayPort Alternate Mode

Yes

Thunderbolt 4 ports quantity

1

USB 2.0 ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

0

USB Power Delivery (USB PD)

Yes

Thunderbolt 5 ports quantity

2

Intel® Thunderbolt 5

Yes

Ethernet LAN (RJ-45) ports

1

USB Type-C charging port

Yes

AC adapter power

280 W

AC adapter frequency

50/60 Hz

AC adapter input voltage

100 - 240 V

Processor cores

24

Processor boost frequency

5.5 GHz

Processor cache

36 MB

Processor threads

24

Performance-core Max Turbo Frequency

5.5 GHz

Processor base power

55 W

Efficient-core Max Turbo Frequency

4.6 GHz

Processor generation

Intel Core Ultra (Series 2)

Efficient-core base frequency

2.1 GHz

Maximum turbo power

160 W

Performance-core base frequency

2.8 GHz

Cable lock slot type

Noble

Smart card reader

Yes

Cable lock slot

Yes

Trusted Platform Module (TPM)

Yes

Trusted Platform Module (TPM) version

2.0

Dell ControlVault

Yes

Operating system architecture

64-bit

Trial software

McAfee Business Protection 1-year (Disti Only),Activate Your Microsoft 365 For A 30 Day Trial

Compatible memory cards

SD, SDHC, SDXC

SSD capacity

1 TB

Storage media

SSD

Optical drive type

No

Number of SSDs installed

1

SSD interface

PCI Express 4.0

Total SSDs capacity

1 TB

SSD form factor

M.2

NVMe

Yes

Total storage capacity

1 TB

Width

360 mm

Depth

258.6 mm

Height (front)

1.73 cm

Height (rear)

1.9 cm
