MB Asrock X850 PRO-A AM5

MB Asrock X850 PRO-A AM5

BIOS type

UEFI AMI

BIOS memory size

256 Mbit

Product colour

Black

1st M.2 largest key size

2280

2nd M.2 largest key size

2280

3rd M.2 largest key size

2280

4th M.2 largest key size

2280

4th M.2 highest PCI Express generation

3.0

1st M.2 highest PCI Express generation

5.0

2nd M.2 highest PCI Express generation

4.0

3rd M.2 highest PCI Express generation

4.0

Number of M.2 (M) slots

4

PCI Express x16 (Gen 5.x) slots

1

PCI Express x16 (Gen 4.x) slots

1

Audio Chip

Realtek ALC897

Audio output channels

7.1 channels

Component for

PC

Motherboard chipset family

AMD

Motherboard form factor

ATX

Windows operating systems supported

Windows 10 x64, Windows 11 x64

Certification

FCC, CE, ErP/EuP

Motherboard chipset

AMD B850

Parallel processing technology support

Not supported

Maximum resolution

3840 x 2160 pixels

HDCP

Yes

USB 2.0 connectors

2

USB 3.2 Gen 1 (3.1 Gen 1) connectors

1

USB 3.2 Gen 2 (3.1 Gen 2) connectors

0

Number of SATA III connectors

4

Front panel audio connector

Yes

ATX Power connector (24-pin)

Yes

CPU fan connector

Yes

EPS power connector (8-pin)

Yes

USB 3.2 Gen 2x2 connectors

1

12V power connector

Yes

Number of CPU fan connectors

2

Number of chassis fan connectors

4

Number of EPS power connectors (8-pin)

2

TPM connector

Yes

RGB LED pin header

Yes

Number of RGB LED pin headers

4

Number of water pump connectors

1

Supported memory types

DDR5-SDRAM

Maximum internal memory

256 GB

ECC сompatibility

ECC & Non-ECC

Number of memory slots

4

Memory slots type

DIMM

Unbuffered memory

Yes

Memory channels

Dual-channel

Ethernet LAN

Yes

Wi-FI

No

Ethernet interface type

2.5 Gigabit Ethernet

LAN controller

Dragon RTL8125BG

Cables included

SATA

Screws included

Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

4

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

0

HDMI ports quantity

1

HDMI version

2.1

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

1

DVI-D ports quantity

0

USB 2.0 ports quantity

6

Processor socket

Socket AM5

Supported processor sockets

Socket AM5

Compatible processor series

AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series

Processor manufacturer

AMD

Line-in

Yes

VGA (D-Sub) ports quantity

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity

1

USB connector type

USB Type-A, USB Type-C

Microphone in

Yes

Ethernet LAN (RJ-45) ports

1

Headphone outputs

3

Supported storage drive interfaces

PCI Express 3.0, PCI Express 4.0, PCI Express 5.0, SATA III

Number of storage drives supported

8

RAID levels

0, 1, 10

Supported storage drive types

HDD & SSD

RAID support

Yes

Width

305 mm

Depth

244 mm

MB-Format

ATX

RAM-Slots

4

MB-Socket

AM5

PCI

0

Serial-or-Paralel

No/No

USB3

4-8

PCI-Ex1

1

PCI-Ex16

1

Onboard-CPU

Yes
