Intel Core Ultra 5 225. Processor family: Intel Core Ultra 5, Processor socket: LGA 1851 (Socket V1), Package type: Tray. Neural processor unit (NPU): Intel AI Boost, AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN, Total processor performance up to: 23 TOPs

Intel Core Ultra 5 225. Processor family: Intel Core Ultra 5, Processor socket: LGA 1851 (Socket V1), Package type: Tray. Neural processor unit (NPU): Intel AI Boost, AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN, Total processor performance up to: 23 TOPs. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR5-SDRAM. On-board graphics card model: Intel Graphics, On-board graphics card outputs supported: HDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1, On-board graphics card base frequency: 300 MHz. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 4.0, 5.0

Execute Disable Bit

Yes

Idle States

Yes

Thermal Monitoring Technologies

Yes

Supported instruction sets

AVX 2.0, SSE4.1, SSE4.2

Embedded options available

Yes

Use conditions

PC/Client/Tablet

Scalability

1S

Direct Media Interface (DMI) Revision

4.0

Market segment

Desktop

PCI Express slots version

4.0, 5.0

Maximum number of PCI Express lanes

24

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)

60 Hz

On-board graphics card base frequency

300 MHz

Number of displays supported (on-board graphics)

4

On-board graphics card refresh rate at maximum resolution (DisplayPort)

60 Hz

On-board graphics card refresh rate at maximum resolution (HDMI)

60 Hz

On-board graphics card DirectX version

12.0

On-board graphics card OpenGL version

4.5

On-board graphics card

Yes

Discrete graphics card

No

Discrete graphics card model

Not available

On-board graphics card model

Intel Graphics

On-board graphics card outputs supported

HDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1

On-board graphics card dynamic frequency (max)

1800 MHz

Xe-cores

2

On-board graphics card ID

0x7D67

Memory channels

Dual-channel

Maximum internal memory supported by processor

192 GB

Memory clock speeds supported by processor

6400 MHz

Memory types supported by processor

DDR5-SDRAM

AI software frameworks supported by NPU

DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

NPU performance up to

13 TOPs

Neural processor unit (NPU)

Intel AI Boost

Sparsity support

Yes

Windows Studio effects support

Yes

Total processor performance up to

23 TOPs

GPU performance up to

4 TOPs

Maximum operating temperature

105 °C

Graphics output

DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b

L2 cache

22528 KB

Maximum internal memory

192 GB

Package type

Tray

Processor threads

10

Maximum turbo power

121 W

Processor ARK ID

241070

Processor model

225

Processor base power

65 W

Processor socket

LGA 1851 (Socket V1)

Efficient-core boost frequency

4.4 GHz

Performance-core boost frequency

4.9 GHz

Processor generation

Intel Core Ultra (Series 2)

AI software frameworks supported by CPU

DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

Processor codename

Arrow Lake

Performance-core base frequency

3.3 GHz

Maximum number of DMI lanes

8

Processor manufacturer

Intel

Processor cache type

Smart Cache

Processor cores

10

Efficient cores

4

Performance cores

6

Efficient-core base frequency

2.7 GHz

Processor cache

20 MB

Processor family

Intel Core Ultra 5

Processor operating modes

64-bit

Processor boost frequency

4.9 GHz

Intel® Thunderbolt 4

Yes

Intel® Turbo Boost Technology

2.0

Enhanced Intel SpeedStep Technology

Yes

Intel® Quick Sync Video Technology

Yes

Intel® AES New Instructions (Intel® AES-NI)

Yes

Intel® Secure Key

Yes

Intel® OS Guard

Yes

Intel 64

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel Virtualization Technology (VT-x)

Yes

Intel Trusted Execution Technology

Yes

Intel® Deep Learning Boost (Intel® DL Boost) on GPU

Yes

Intel® Speed Shift Technology

Yes

Intel® Control-flow Enforcement Technology (CET)

Yes

Intel® Thread Director

Yes

Intel® Boot Guard

Yes

Intel® Deep Learning Boost (Intel® DL Boost) on CPU

Yes

Intel® Volume Management Device (VMD)

Yes

Mode-based Execute Control (MBE)

Yes

Intel® Standard Manageability (ISM)

Yes

Status

Launched

OpenCL version

3.0

Launch date

Q1'25
