N300 Wi-Fi 4G LTE Router, Build-In 150Mbps 4G LTE Modem SPEED: 300 Mbps at 2.4 GHz, 4G Cat4 150/50 Mbps SPEC: 2× Fixed External Antennas, 3× 10/100 Mbps LAN Port, 1× 10/100 Mbps WAN/LAN Port, FDD-LTE (B1/B3/B5/B7/B8/B20/B28), TDD-LTE (B38/B40), HSPA+/UMTS (B1/B5/B8) FEATURE: MERCUSYS APP, Nano SIM

N300 Wi-Fi 4G LTE Router, Build-In 150Mbps 4G LTE Modem SPEED: 300 Mbps at 2.4 GHz, 4G Cat4 150/50 Mbps SPEC: 2× Fixed External Antennas, 3× 10/100 Mbps LAN Port, 1× 10/100 Mbps WAN/LAN Port, FDD-LTE (B1/B3/B5/B7/B8/B20/B28), TDD-LTE (B38/B40), HSPA+/UMTS (B1/B5/B8) FEATURE: MERCUSYS APP, Nano SIM Card Plug and Play, 3G/4G Router/Wi-Fi Router Mode, IPTV, IPv6, Parental Controls

Antenna design

External

Antennas quantity

4

WPS push button

Yes

Product type

Tabletop router

Reset button

Yes

ADSL

No

Ethernet LAN

Yes

DHCP server

Yes

Ethernet LAN data rates

10,100 Mbit/s

Ethernet LAN interface type

Fast Ethernet

Wi-Fi Multimedia (WMM)/(WME)

Yes

4G bands supported

700,800,850,900,1800,2100,2300,2600 MHz

3G bands supported

850,900,2100 MHz

Mobile network generation

4G

4G standard

LTE-TDD & LTE-FDD

SIM card type

NanoSIM

Top Wi-Fi standard

Wi-Fi 4 (802.11n)

Wi-Fi band

Single-band (2.4 GHz)

Maximum Tx power (2.4 GHz)

74.5 dBmW

Security algorithms

WPA-PSK, WPA2-PSK

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-40 - 60 °C

Storage relative humidity (H-H)

5 - 90%

Cables included

LAN (RJ-45)

Quick installation guide

Yes

Ethernet LAN (RJ-45) ports

4

Ethernet WAN

Yes

Power source type

DC

Height

32 mm

Depth

140 mm

Width

219 mm

WLAN data transfer rate (max)

300 Mbit/s

Frequency-Band

SingleBand

Port-Type

FastEthernet

WAN-Ports

1

Wireless-Speed

300Mbps

WR-LAN-Ports

1

USB-Port

No

WiFi-Standard

ac
