MR85X Mercusys AX3000. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 6 (802.11ax), WLAN data transfer rate (max): 3000 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology

Mercusys AX3000. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 6 (802.11ax), WLAN data transfer rate (max): 3000 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Security algorithms: WPA, WPA2, WPA2-Personal, WPA3-Personal, Firewall security: SPI Firewall, IP and MAC Address Binding. Product type: Tabletop router, Product colour: Black, LED indicators: Activity

Antenna type

2x2

Antenna design

External

Antenna direction type

Omni-directional

Antennas quantity

4

Product colour

Black

Built-in display

No

Product type

Tabletop router

LED indicators

Activity

WPS push button

Yes

Reset button

Yes

Ethernet LAN interface type

Gigabit Ethernet

Ethernet LAN

Yes

Ethernet LAN data rates

10,100,1000 Mbit/s

DHCP client

Yes

DHCP server

Yes

Networking standards

IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Wi-Fi Multimedia (WMM)/(WME)

Yes

Quality of Service (QoS) support

Yes

Universal Plug and Play (UPnP)

Yes

Port forwarding

Yes

MU-MIMO technology

Yes

Cabling technology

10/100/1000Base-T(X)

Modulation

OFDMA

Parental control

Yes

Firewall security

SPI Firewall, IP and MAC Address Binding

Remote management

Yes

Port triggering

Yes

Wi-Fi band

Dual-band (2.4 GHz / 5 GHz)

Top Wi-Fi standard

Wi-Fi 6 (802.11ax)

Number of guest networks (5 GHz)

1

Wireless radio

Yes

Number of guest networks (2.4 GHz)

1

Wi-Fi standards

802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

VPN server

OpenVPN/PPTP/L2TP/IPSec VPN Server and Clients

Security algorithms

WPA, WPA2, WPA2-Personal, WPA3-Personal

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 90%

Storage relative humidity (H-H)

5 - 90%

Quick installation guide

Yes

Cables included

LAN (RJ-45)

AC adapter included

Yes

Package type

Box

Ethernet LAN (RJ-45) ports

3

DC-in jack

Yes

Memory card slot(s)

No

Ethernet WAN

Yes

Power source type

AC

DMZ support

Yes

Guest access

Yes

Firewall

Yes

DSL WAN

No

SIM card slot

No

3G/4G USB modem compatibility

No

WAN connection type

RJ-45

Depth

171.7 mm

Width

209 mm

Height

42.4 mm

WLAN data transfer rate (second band)

574 Mbit/s

WLAN data transfer rate (first band)

2402 Mbit/s

WLAN data transfer rate (max)

3000 Mbit/s
