Sursa DEEPCOOL PF500 80 PLUS Standard

Sursa DEEPCOOL PF500 80 PLUS Standard, Active PFC+Double tube forward, Eficienta 85% sub incarcare tipica, Protectie OPP/OVP/SCP/UVP

Number of fans

1 fan(s)

Fan diameter

12 cm

On/off switch

Yes

Cables included

AC

80 PLUS certification

80 PLUS

Mean time between failures (MTBF)

100000 h

Purpose

PC/Server

Power supply unit (PSU) form factor

ATX

ATX version

2.4

Peripheral (Molex) power connectors (4-pin)

0

PCI Express power connectors (6+2 pin)

2

Motherboard power connector

20+4 pin ATX

Motherboard power cable length

55 cm

EPS power connector (4+4 pin)

Yes

Cabling type

Non-Modular

Number of SATA power connectors

4

SATA power cable length

450,600,750,900 mm

Power protection features

Over power, Over voltage, Short circuit, Under voltage

Total power

500 W

Combined power (+12V)

480 W

Max output current (+12V)

40 A

AC input frequency

50 Hz

AC input voltage

220 - 240 V

Hold time

16 ms

Combined power (+3.3V)

100 W

Combined power (+5V)

100 W

Combined power (-12V)

3.6 W

Combined power (+5Vsb)

12.5 W

Max output current (+3.3V)

15 A

Max output current (+5V)

15 A

Max output current (-12V)

0.3 A

Max output current (+5Vsb)

2.5 A

Depth

140 mm

Width

150 mm

Height

86 mm
