Sursa DEEPCOOL PF700X 700W, ATX, ACTIVE PFC, 80 PLUS BRONZE

Sursa DEEPCOOL PF700X 700W, ATX, ACTIVE PFC, 80 PLUS BRONZE

Compliance certificates

CCC, CE, KC, RCM, TÜV mark, WEEE

On/off switch

Yes

Product colour

Black

Cooling type

Active

Number of fans

1 fan(s)

Fan diameter

12 cm

Fan location

Top

PFC

Active

Warranty period

3 year(s)

Operating temperature (T-T)

0 - 40 °C

Screws included

Yes

Cable tie(s) included

Yes

Cable ties included

Yes

Cables included

AC

Package type

Box

ATX version

2.52

Bearing technology

HYB

Mean time between failures (MTBF)

40000 h

Purpose

PC

80 PLUS certification

80 PLUS Bronze

Power supply unit (PSU) form factor

ATX

Cabling type

Non-Modular

Motherboard power cable length

55 cm

CPU power connector (4+4 pin)

Yes

ATX power connector (20+4 pin)

Yes

PCI Express connector

Yes

Motherboard power connector

20+4 pin ATX

Peripheral (Molex) power connectors (4-pin)

1

Number of SATA power connectors

3

PCI Express power cable length

55 cm

Peripheral (Molex) power cable length

900 mm

PCI Express power connectors (6+2 pin)

2

Number of SATA power cables

2

SATA power cable length

450,600,750 mm

CPU power cable length

62 cm

Efficiency

88%

Combined power (+12V)

3.6 W

Max output current (-12V)

58.3 A

AC input frequency

50/60 Hz

Combined power (-12V)

699.6 W

AC input voltage

200 - 240 V

Max output current (+3.3V)

18 A

Hold time

16 ms

Combined power (+5V)

110 W

Total power

500 W

Input current

5 A

Max output current (+5V)

18 A

Max output current (+12V)

0.3 A

Combined power (+5Vsb)

15 W

Max output current (+5Vsb)

3 A

Power Factor Correction (PFC) type

Active

Combined power (+3.3V)

110 W

Sustainability certificates

ErP, Triman

PSU Type

ATX

PSU Power

700 W

Conectivitate

Non Modular

Iluminare RGB

Nu

Certificare 80 Plus

80 PLUS Bronze

Depth

140 mm

Height

86 mm

Width

150 mm

Modular

No

PSU-Power

501W-750W
