Zyxel 8-port GbE Smart Managed PoE Switch with GbE Uplink

Zyxel 8-port GbE Smart Managed PoE Switch with GbE Uplink

Certification

CE, FCC, RCM, Class A, BSMI CNS 13438, LVD EN 62368-1, BSMI CNS 14336-1

Throughput

14.88 Mpps

MAC address table

8000 entries

Jumbo frames

9000

Switching capacity

20 Gbit/s

Rack mounting

No

Stackable

No

LED indicators

Yes

Wall mountable

Yes

Mean time between failures (MTBF)

800259 h

VLAN support

Yes

Quality of Service (QoS) support

Yes

Web-based management

Yes

System event log

Yes

Switch type

Managed

Switch layer

L2

MIB support

RFC 1213 MIB II, RFC 2819 RMON (group 1, 2, 3, 9), RFC 1215 generic traps, RFC 1493 bridge

Virtual LAN features

Voice VLAN

Copper ethernet cabling technology

10BASE-T, 100BASE-T, 1000BASE-T

10G support

No

Power over Ethernet (PoE)

Yes

Storage relative humidity (H-H)

10 - 95%

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 95%

Storage temperature (T-T)

-40 - 70 °C

Cables included

AC

SFP+ module slots quantity

2

Console port

RJ-45

Basic switching RJ-45 Ethernet ports quantity

8

Power over Ethernet (PoE) ports quantity

8

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

SFP module slots quantity

2

Power supply included

Yes

Power source

AC

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Power consumption (max)

95.3 W

Total Power over Ethernet (PoE) budget

77 W

Management protocols

SNMP, RMON, ICMP, Syslog

Security algorithms

802.1x RADIUS, SSL/TLS

IGMP snooping

Yes

DHCP features

DHCP client

MAC address filtering

Yes

Weight

720 g

Height

27 mm

Depth

104 mm

Width

250 mm

Rackable

Yes

LAN-Port-Type

Gigabit

LAN-Ports

8

Redundant-PSU

No

Layer

Layer-2
