Omada 10G Multi-Gigabit RJ45 to 10G SFP+ Slot Supporting MiniGBIC Modules PORT: 1× 10G SFP+ Slot, 1× 10G Multi-Gigabit RJ45 Port (Auto MDI/MDIX) SPEC: Chassis MC1400 Rack-mountable

Omada 10G Multi-Gigabit RJ45 to 10G SFP+ Slot Supporting MiniGBIC Modules PORT: 1× 10G SFP+ Slot, 1× 10G Multi-Gigabit RJ45 Port (Auto MDI/MDIX) SPEC: Chassis MC1400 Rack-mountable

Compliance certificates

RoHS, UL

Maximum data transfer rate

10000 Mbit/s

Internal

No

LED indicators

Activity, Link, Power

Networking standards

IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3x, IEEE 802.3z

Copper ethernet cabling technology

2.5GBASE-T, 10GBASE-T, 1000BASE-T

Duplex system

Full, Half

Data transfer rate

10000 Mbit/s

Auto-negotiation

Yes

Storage relative humidity (H-H)

5 - 90%

Operating temperature (T-T)

0 - 50 °C

Storage temperature (T-T)

-40 - 70 °C

Operating relative humidity (H-H)

10 - 90%

Connectivity technology

Wired

Fiber mode structure

Multi-mode, Single-mode

Maximum transfer distance

100 m

Fiber ports quantity

1

Fiber optic connector

SFP+

Power consumption (max)

4.12 W

Width

94.5 mm

Height

27 mm

Depth

7.3 mm

LAN-Port-Type

FastEthernet
