Omada 20-Port Gigabit Easy Managed Switch with 16-Port PoE+ PORT: 16× Gigabit PoE+ Ports, 2x Gigabit Non-PoE Ports, 2× Gigabit SFP Ports SPEC: 802.3at/af, 250 W PoE Power, 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with Omada SDN Controller and Omada Cloud Essentials, Fast PoE

Omada 20-Port Gigabit Easy Managed Switch with 16-Port PoE+ PORT: 16× Gigabit PoE+ Ports, 2x Gigabit Non-PoE Ports, 2× Gigabit SFP Ports SPEC: 802.3at/af, 250 W PoE Power, 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with Omada SDN Controller and Omada Cloud Essentials, Fast PoE, Perpetual PoE, Flow Control, Loopback Detection, Port Isolation, Port Mirroring, LAG, VLAN, IGMP Snooping, QoS, Storm Control

Compliance certificates

CE, Federal Communications Commission (FCC), RoHS

Forwarding rate

1.488 Mpps

Jumbo frames

15

Store-and-forward

Yes

Jumbo frames support

Yes

MAC address table

8000 entries

Switching capacity

20 Gbit/s

Packet buffer memory

4 MB

Stackable

No

Reset button

Yes

Wall mountable

Yes

Networking standards

IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x

VLAN support

Yes

Quality of Service (QoS) support

Yes

Flow control support

Yes

Switch type

Managed

Cloud-managed

Yes

Virtual LAN features

MTU VLAN, Port-based VLAN, Tagged VLAN

Power over Ethernet (PoE)

Yes

Port mirroring

Yes

Link aggregation

Yes

Auto-negotiation

Yes

10G support

No

Auto MDI/MDI-X

Yes

Storage relative humidity (H-H)

5 - 90%

Operating temperature (T-T)

0 - 40 °C

Transmission distance (max)

0.25 km

Cables included

AC

Package type

Box

Fanless

Yes

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Basic switching RJ-45 Ethernet ports quantity

10

Combo SFP ports quantity

1

Input current

2.43 A

DC input voltage

53.5 V

Power source

DC

Power supply included

Yes

Power over Ethernet (PoE) power per port

30 W

Power over Ethernet plus (PoE+) ports quantity

8

Total Power over Ethernet (PoE) budget

123 W

DHCP features

DHCP client

IGMP snooping

Yes

Height

26 mm

Depth

126 mm

Width

209 mm

Rackable

No

LAN-Port-Type

FastEthernet

LAN-Ports

8

Redundant-PSU

No
