SOCOMEC ITYS 1000VA VFI UPS 1/1 PF=1 WITH BATTERY INTEGRATED
- Embedded dry-contact interface.
- Input mains switch breaker.
- Connection for battery extension modules.
- Power off the UPS remotely.
- Internal temperature sensor.
Input connection C14
Number of output connections C13 4 pcs
- Battery capacity
- 7 Ah
- Typical backup time at full load
- 7.8 min
- Charging current
- 8 A
- Battery technology
- Sealed Lead Acid (VRLA)
- Battery life (max)
- 3 year(s)
- Battery voltage
- 3.6 V
- Certification
- IEC/EN 62040-2, AS 62040.2
IEC/EN 62040-3
CE, RCM (E2376)
- Product colour
- Black, Grey, Orange
- LED indicators
- Yes
- International Protection (IP) code
- IP20
- Display type
- LCD
- Control type
- Buttons
- Form factor
- Mini Tower
- ECO mode
- Yes
- Output frequency
- 50/60 Hz
- Number of input phases
- 1
- Number of output phases
- 1
- Efficiency (ECO mode)
- 98%
- UPS topology
- Double-conversion (Online)
- Input frequency
- 40 - 70 Hz
- Crest factor
- 3:1
- Output operation voltage (min)
- 200 V
- Efficiency
- 93%
- Input power factor
- 0.99
- Waveform
- Sine
- Input operation voltage (max)
- 300 V
- Output operation voltage (max)
- 240 V
- Emergency Power Off (EPO)
- Yes
- Output power capacity
- 1 kVA
- Input operation voltage (min)
- 160 V
- Output power
- 1000 W
- Output power factor
- 1
- Power protection features
- Short circuit
- Noise level
- 50 dB
- Country of origin
- China
- Operating temperature (T-T)
- 0 - 45 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Operating altitude
- 0 - 1000 m
- AC outlets quantity
- 4 AC outlet(s)
- AC outlet types
- C13 coupler
- Power plug
- C14 coupler
- USB port type
- USB Type-B
- RS-232 ports
- 1
- Safety
- IEC/EN 62040-1, AS 62040.1.1, AS 62040.1.2
- Width
- 145 mm
- Weight
- 14.4 kg
- Depth
- 40.4 mm
- Height
- 224 mm
